Monitor Audio CSS230 In-Ceiling Speaker

Sold Out



The CSS230 is a brilliantly innovative back-box design with an impressively shallow 50 mm (2") mounting depth, custom built to offer hi-fi levels of performance in spaces where no high quality speaker has gone before.

Between 2" stud frames or where pipework or cabling reduces mounting depth, the hybrid back-box construction and proprietary full-range driver array combine to deliver consistent audio quality with exceptional installation versatility.

The hybrid back-box provides the best of all worlds for installer and customer. Combined, the three proprietary 3" mid-bass units achieve the bass output of a 6 1/2" driver, all from a super-stealthy flush-fitted profile.

In keeping with Monitor Audio’s renowned design rigour, the crossover comprises high quality film capacitors and low loss inductors - selected for signal integrity - ensuring peerless audio detail and dynamics from a speaker of its size and application. When the CSS230 is in ‘ported’ mode, a fine gauze protects the acoustic system from dust ingress.

Ideal for restricted installations where a shallower mounting depth is required.

The CSS230 is available with either round or square grilles. Sold as a single unit.
  •     Sensitivity (1W @ 1M): 86 dB
  •     Cut-Out Diameter: 210 mm
  •     Mounting Depth: 50 mm
  •     Power Handling (RMS): 40 Ws
  •     Nominal Impedance: 8 ohms
  •     Driver Size: 3 " (x3)
