Nordost Heimdall II Digital Interconnects

Nordost Heimdall II Digital Interconnects

Nordost Heimdall II Digital Interconnects

$1,780.00

Please contact us to order

Length: 1m

1m

1.5m

2m

Connection: BNC

BNC

Product variants

Digital data transfer demands precise impedance matching in both cable and connectors. Manufactured entirely in the USA, the Heimdall 2 S/PDIF and AES/EBU cables are optimized for digital signal transfer and use a silver-plated OFC solid core conductor suspended in our proprietary, precision Dual Mono-Filament construction.

Quantity

Free Shipping for orders $500+

Availability

Ask a question

Specifications

Insulation: Fluorinated Ethylene Propylene (FEP)
Construction: Mechanically tuned spacing, length and Dual Mono-Filament, co-axial design
Conductors: 1 x 20 AWG
Material: Silver-plated 99.99999% solid-core OFC
Capacitance: 15.0pF/ft
Impedance: 75 Ohm
Overall Shield Coverage: 97%
Velocity of Propagation: 88%
Termination: Gold-plated true 75 Ohm Neutrik BNC. Gold-plated BNC to RCA adapter included.

Nordost’s ultra-close tolerance digital transfer solutions deliver the goods, sonically and musically.

Stereophile

In the S/PDIF cable, this technology is combined with combination BNC/RCA connectors, providing a true 75 Ohm signal path which answers the demand for the precise tolerance needed for clocking and dealing with digital output. Whereas the AES/EBU cable is constructed with impedance matched XLR connectors, providing a true 110 Ohm signal path for digital data which results in clearly audible sonic and musical benefits. The result is an ultra high-speed, low-loss cable specifically designed to deliver the best possible performance from today’s high-resolution digital audio sources. They may only be “ones” and “zeros” but poor impedance matching has a dramatic impact on the accuracy with which they are passed from one electronic device to another. Nordost’s ultra-close tolerance digital transfer solutions deliver the goods, sonically and musically.
