Technics SL1300G Grand Class Turntable

Name: Technics SL1300G Grand Class Turntable
Brand: Technics
Price: 5500.00 NZD
Availability: InStock

$5,500.00

Sold out

Tax included.

Product variants

New generation Grand Class turntable

Turntable with a Hi-Fi design featuring ΔΣ-Drive, a new motor drive technology that delivers high rotational accuracy and low vibration. The turntable’s new motor, three-layer platter, and high-rigidity chassis ensure even higher sound quality.

Quantity

Free Shipping for orders $500+

Specifications

Turntable Section

Drive Method: Direct Drive
Motor: Brushless DC motor
Turntable Speeds: 33-1/3, 45 and 78 rpm
Pitch Adjustment Range : ±8% and ±16%
Starting Torque: 0.32 N・m (3.3kgf・cm) (2.86 lbf-in)
Build-up Characteristics: 0.7 s. from standstill to 33- 1/3 rpm
Braking system: Electronic brake
Wow and Flutter: 0.025%　W.R.M.S.
Turntable Platter: Aluminium diecast, Brass and Rubber, Diameter：332mm (13-5/64″)
Platter Weight：Approx. 3.6kg (7-15/16lbs) (Including a rubber sheet)

Tonearm Section

Type: Static Balance
Effective Length: 230mm
Overhang :15mm
Tracking Error Angle:

Within 2° 32’　(at the outer groove of 30cm(12″) record)
Within 0° 32’　(at the inner groove of 30cm(12″) record)

Offset Angle: 22°
Arm Height Adjustment Range: 0 – 6mm
Stylus Pressure Adjustment Range: 0 – 4g (Direct Reading)
Headshell weight: Approx. 7.6g
Applicable Cartridge Weight Range

(without auxiliary weight)
5.6 – 12.0g
14.3 – 20.7g (including head shell)
(with small auxiliary weight)
10.0 – 16.4g
18.7 – 25.1g (including head shell)
(with big auxiliary weight)
14.3 – 19.8g
23.0 – 28.5g (including head shell)

Cartridge Mounting Dimension: 12.7 mm (1/2″) interval
Head Shell Terminal Lug: 1.2mmφ 4-pin terminal lug

Terminals

Audio Output: PHONO (Pin Jack) x 1, EARTH TERMINAL x 1

General

Power Supply: AC220-240 V, 50/60 Hz
Power Consumption:
10 W (ON)
0.3 W (OFF)
Dimensions (W x H x D): 453 x 173 x 372 mm
Weight :Approx. 13.0kg
Operating temperature range: 0℃ to +40℃
Operating humidity range :35% to 80% RH (no condensation)
Accessories:

An end-game solution for persons seeking a durable, precisely engineered tool for enjoying their record collection.

Stereophile

Motor-Drive System, ΔΣ-Drive

Unlock a realm of audio precision with the ΔΣ-Drive – a state-of-the-art system harnessing Technics’ expertise in PWM signal processing. In addition to reducing harmonics, the drive suppresses vibrations from the motor for smoother, more accurate rotation, ensuring a rich reproduction of the music.

Three-layered Turntable Platter

The turntable has a three-layered construction with a rigidly combined brass and aluminium die-cast platter. With a deadening rubber covering its entire rear surface to eliminate unnecessary resonance, thereby achieving high rigidity and vibration damping. This delivers smooth rotational stability and inertial mass surpassing the SP-10MK2, the direct-drive turntable standard used by broadcast stations worldwide, as well as having more than twice the inertial mass of the SL-1200MK5.

High-level Balance Adjustment

When the weight distribution of the turntable is uneven, excess vibration or noise occurs during rotation, which causes degradation in sound quality. Therefore, the balance of the turntable is adjusted at the factory by using specialized high-precision balance adjustment equipment for each and every item after the turntable is assembled. Turntables that have undergone adjustment are labelled with a sticker reading “BALANCED” to indicate that adjustment has been done.

Active Noise Cancelling

This technology combines a noise detection device with an error amplifier. It detects residual noise in the power supply and applies an inverse phase current to remove noise components. It removes low frequency noise more effectively than a regulator to ensure a more ideal power supply.

Free turntable setup

We carefully set up every turntable and cartridge we sell. So if you're new to turntables or have decades of experience, you know you'll be getting the most enjoyment from your system. You can be safe in the knowledge that you can take your turntable home, plug it straight in and start enjoying good music without any worry of something being setup incorrectly.

Like all Technics turntables, the SL-1300G was engineered to be set up easily and correctly by average users, and to last decades under heavy use. In my system, the 1300G performed like a Class A turntable at a Class B price. That's why it's my new budget reference.

One of the reasons the vinyl format is so prized is the naturalistic way it can have with tempo, rhythm, and timing when it’s properly implemented, and this Technics has this talent in abundance.

Thanks to its iconic status, handsome looks and superb build quality at the price, this deck could find many new owners even if it was a less proficient turntable than it actually is. But happily, it also justifies its position in the market thanks to its fine sound quality.
