Marantz Model 30 Integrated Amplifier

Marantz Model 30 Integrated Amplifier

Name: Marantz Model 30 Integrated Amplifier
Brand: Marantz
Price: 5999.00 NZD
Availability: OutOfStock

$5,999.00

Sold out

Product variants

A masterpiece of audio architecture

Featuring a fully discrete, two stage design for minimal interference, and unique Marantz HDAM technology for signal purity, MODEL 30 offers exceptional sound quality.

MODEL 30 continues the renowned heritage of exquisite Marantz amplifiers. Tuned by the Marantz Sound Master who channeled his passion, experience, and extraordinary ear into the amplifier design.

Specifications

Rated Output Power: 100W + 100W (8ohm) 200W + 200W (4ohm)

Amplifier Circuit Switching Amp: (Hypex NC500/SMPS600 by single)

Power Trans: Toroidal w/case

Volume: Electric

Loudness No

Bass / Treble / Mid / Balance Control: yes / yes / No / yes

REC Out Select: No

Source Direct: yes

Pure Direct: No

(Marantz) Purest Mode: No

Isolator (for USB-B input): No

Jitter reducer: No

Dual Clock: 44.1 / 48 kHz: No

Digital Filter: No

Analog Amp Mode: No

Wide Range: 5Hz - 50kHz

Total Harmonic Distortion: 0.005% (1kHz, 8Ω)

Damping Factor: 500

Input Sensitivity: Phono input MM: 2.3 mV / 39 kohm MC: 250

Input Sensitivity: CD/Line/Recorder 220 mV / 13 kohm

Input Sensitivity: Power Amplifier input 1.1 V / 13 kohm

SN Ratio PHONO (MM): 88dB PHONO (MC): 75dB CD: 107dB

The Most Musical, Accurate, Detailed Sound

MODEL 30 is built on its own discrete circuit board, the Hyper-Dynamic Amplifier Module, or HDAM. By custom-curating hundreds of individual parts, rather than adopting an off-the-shelf solution, the MODEL 30 HDAM significantly outperforms standard integrated circuits to create the unique musicality you always expect from Marantz.

Marantz Musical Premium Phono EQ

Envisioned to deliver optimal sound quality by simplifying the signal path – vital given the delicate nature of phono signals – the Phono EQ stage in MODEL 30 can be used with both moving magnet and low-output moving coil cartridges, thanks to a built-in MC head amplifier.

MC / MM Phono Input Impedance Selector

In order to optimize sound performance when using a moving coil (MC) or magnetic moving (MM) cartridge, and to accommodate all configurations as much as possible, MODEL 30 is equipped with an input impedance selector. The input impedance can be adjusted to three different settings: MC LOW (33 ohm), MC MID (100 ohm) and MC HIGH (390 ohm)
