Specifications
Rated Output Power: 70W + 70W (8ohm) 100W + 100W (4ohm)
Power Amplifier Circuit: HDAM-SA3
Power Transformer: Double Shielded Toroidal
Volume: Electric
Bass / Treble / Mid / Balance Control: yes / yes / - / yes
Source Direct: yes
Frequency Response: 5Hz - 50kHz
Total Harmonic Distortion: 0.02% (20Hz - 20kHz, 8Ω)
Damping Factor: 100
Input Sensitivity: Phono input 2 mV / 47 kohm
Input Sensitivity: CD/Line/Recorder 220 mV / 20 kohm
Input Sensitivity: Power Amplifier input 1.6 V / 15 kohm
SN Ratio PHONO (MM): 87dBCD: 106dB
Phono Input: yes (MM) Marantz Musical Phono EQ
Ext. Pre Input (Power Amp Direct): yes
Preout: no
Analog Input: (include Phono) / REC Out (RCA) 4 (PHONO, CD, LINE,RECORDER) / 1 (RECORDER)
Optical input: 1
Coaxial input: 1
HDMI: 1 / 0 (ARC) PCM only
USB A: 1 (Rear), Mass Storage Class5V/1A
Speaker Terminal SPKT-1+
Remote Control Bus Terminal: yes (RC-5 In / Out)
Subwoofer Pre-out Low Pass Filter: Selectable 40 Hz / 60 Hz / 80 Hz /100 Hz / 120 Hz
Power Consumption: 220W, 0.3W (Standby)
AC Inlet: yes
Quick Start Guide: Included
Packaging Dimensions: (W x H x D in inches) 21" x 10" x 20.6"
Product Dimensions: (W x H x D in inches) 17.4" x 5.1" x 17"
