Meridian 258 Power Amplifier

$3,600.00

View All Meridian

Details

Specifications

2 Channel 200w Power Amplifier

The Meridian 258 is our dedicated rack-mount Eight Channel Power Amplifier. This powerful, high performance, cool-running Class D amplifier is suitable for a wide range of applications. At only 1U high, the compact 258 is a category changing amplifier; bringing Meridian high resolution sound quality to every zone it powers.

Featuring a highly efficient, cool and fan less construction, the Meridian 258 provides a truly ‘fit and forget’ solution when driving multiple zones. An audiophile approach has been taken to the 258’s component selection, resulting in a level of performance typically associated with power amplifiers offered at a significantly higher price.

AUDIO INPUTS

Eight RCA inputs

AUDIO OUTPUTS

70W into 8 Ohms per channel

100W into 4 Ohms per channel

Phoenix Connectors supplied for ease of installation 24-12 AWG cable

CONTROL

REAR PANEL: Trigger input [3.5mm 5-30 VDC]

FRONT PANEL: On/Off Switch

DISPLAY

LEDs to indicate ‘Standby’ [Blue], ‘On’ [White], ‘Overload’ [Red]

DIMENSIONS

HEIGHT: 44mm [1.73in]

WIDTH: 480mm [18.9in]

DEPTH: 360mm [14.17in]

WEIGHT: 5.5Kg [12.13lbs]

CONSTRUCTION

All aluminium construction

Optional standalone feet pads supplied

POWER

Advanced linear power supply: 100V ac 50/60 Hz | 110-120V ac 50/60Hz | 220-240V ac 50/60Hz
