TECHNOLOGY
• Projection System: RGB liquid crystal shutter projection system
• LCD Panel: 0.74-inch wide panel with MLA (C2 Fine, 12 bit, OD)
• Pixel Number: 2,073,600 dots (1920 x 1080)
• Resolution: 4K Enhancement (1920 x 1080 x 2)
OPTICAL
• Zoom: 1 - 2.1 (Optical)
• Screen Size:
-50" to 300" [1.48 to 9.08 m] (Zoom: Wide)
-50" to 300" [3.13 to 18.99 m] (Zoom: Tele)
• Projection Distance: 100" screen 3.0 - 6.3 m
• Throw Ratio:
- 1.35 (Zoom: Wide)
- 2.84 (Zoom: Tele)
• Projection Lens F Number: 2.0-3.0
• Projection Lens Focal Length: 22.5mm - 46.7mm
• Focus Method: Powered
• Colour Light Output: 2,600 Lumens
• White Light Output: 2,600 Lumens
• Native Aspect Ratio: 16:9
• Contrast Ratio: 1,200,000:1
• Lamp Type: 250 W UHE
• Colour Reproduction: Up to 1.07 billion colours
• Colour Processing: 10 bit (12 bit Digital Colour Processing)
• Keystone Correction:
- Vertical: -30 to +30 degrees
• Lens Shift (Powered)
- Vertical: -96.3% to +96.3%
- Horizontal: -47.1% to +47.1%
CONNECTIVITY
• Input: Digital 2 x HDMI (1 x HDCP2.2)
• Input: Computer 1 x D-sub 15-pin (RGB)
• Input: Opt. HDMI 1 x USB A
• Input: Control 1 x RS232c
• Input: Network I/O 1 x RJ45, 1 x USB Type A (for optional Wireless LAN unit)
• Trigger Out: 3.5 mm mini-jack
• Wireless Connectivity Optional
ADVANCED FEATURES
• Super Resolution
• High Dynamic Range - HDR10
• Hybrid Log Gamma - HLG
• Image Enhancement
• Frame Interpolation
• 4K Enhancement
• 3D Formats: Top-and-Bottom, Side-by-Side
• Direct Power On
• Security: Kensington®-style lock provision
• Aspect Modes: Yes (Auto / Normal / Full / Zoom / Anamorphic Wide / Horiz.Squeeze)
• Colour Modes
- 2D: Dynamic, Bright Cinema, Natural Cinema, Digital Cinema
- 3D: 3D Dynamic, 3D Cinema
GENERAL
• Dimensions D x W x H: 450 x 520 x 192.7 mm
• Weight: 11.2kg
• Lamp Warranty: 3 Years
• Projector Warranty: 3 Years
• Power Consumption: Lamp on 298 W
• Power Consumption: Standby 2 W
• Noise Level (Normal/Eco): 31/20 dB
